3-Phase Power Supply, Primary Switch Mode for Universal Use – QUINT 48 V DC/10 A
3. Technical Data
125 mm
(4.921 in.)
L1 (+)
L2
L3 ( –)
PE
DC OK
13
14
160 mm
(6.299 in.)
QUINT 48 V DC/10 A
3 AC
Schem
CB U
uB
solid
[mm 2 ]
? exible
AWG
torque
[Nm] [Ib in.]
Stripping Lengths
[mm]
Input
Output
Signal
Description
0,2-6
0,5-16
0,5-16
0,2-4
0,5-10
0,5-10
24-10 0,5-0,6 4,4-5,3
20-6 1,2-1,5 10,6-13,3
20-6 1,2-1,5 10,6-13,3
8 mm (0.31 in.)
10 mm (0.39 in.)
10 mm (0.39 in.)
Type
Order No.
Pcs .
Pkt.
Power Supply ,
Primary switch mode for universal use
QUINT-PS-3x400-500AC/48DC/10
29 38 21 9
1
Technical Data
Input Data 1
Nominal input voltage
Input voltage range
Frequency
Current consumption (for nominal values)
Inrush current limiting/I 2 t (+25°C [+77°F])
Mains buffering for a nominal load (typical)
Switch-on time after applying the mains voltage
Transient surge voltage protection
Input fuse, internal
Recommended fuse
Discharge current for PE
Output Data 2
Nominal output voltage U N /tolerance
Setting range for the output voltage
Output current (continuous) during convection cooling and nominal
values POWER BOOST I BOOST -25°C to +40°C (-13°F to +104°F)
Nominal output current I N -25°C to +60°C (-13°F to +140°F)
Derating
Short-circuit current limit
Startup of capacitive loads
System deviation on: Load change static 10 - 90%
Load change dynamic 10 - 90%
Input voltage change ±10%
Maximum power loss No load/nominal load
Ef ? ciency
Response time U OUT (10% - 90%)
Residual ripple/switching peaks (20 MHz)
Can be connected in parallel
Internal surge voltage protection
Resistance to return supply
Signal Output Data
DC OK (active) 3
(U out > 0.9 x U N = high signal)
DC OK (electrically isolated) 4
(U out > 0.9 x U N = contact closed)
LED 6 (U out < 0.9 x U N = LED ? ashing)
3 x 400 - 500 V AC (wide range input)
3 x 320 - 575 V AC 450 - 800 V DC
45 - 65 Hz 0 Hz
3 x 1.2 A (400 V AC)/3 x 1.0 A (480 V AC), approximately
15 A, approximately/1 A 2 s, approximately
> 20 ms (for 3 x 400 V AC)/> 30 ms (for 3 x 480 V AC)
<1s
Varistor
(Device protected by a circuit breaker)
3 x circuit breaker 6, 10 or 16 A
Characteristic B (EN 60 898)
< 3.5 mA
48 V DC ±1%
40 - 56 V DC
13 A (U out = 48 V DC)
10 A (U out = 48 V DC)
From +60°C (+140°F), 2.5% per Kelvin
I BOOST ≈ 13 A, approximately
Unlimited
< 1%, typical
< 5%, typical
< 0.1%, typical
10 W/45 W, approximately
> 90% (for 400 V AC and nominal values)
< 10 ms, typical
< 200 mV pp (for nominal values)
To increase redundancy and power
Yes, limited to 60 V DC, approximately
60 V DC
+24 V DC signal (with regard to the device weight)
20 mA, maximum
60 V AC/DC, maximum; 0.5 A, maximum
Green LED
PHOENIX CONTACT page 2 of 10
